Art Projectors Studio
Rotterdam · Est. 2017
Each model in the Art Projectors Studio range ships factory color-calibrated against the Rec.2020 reference, with a printed certificate inside the box. Choose by lumen class and housing — every unit carries the same APS-Edge blending engine and the same five-year color-consistency guarantee.
01
The studio workhorse. 6,500 lumens, Rec.2020-calibrated, silent-housing. Built for single-wall video art in a working artist's studio or a small gallery room.
02
The flagship mid-room unit. 11,000 lumens, native 4K, hardware edge-blend node for up to eight-projector arrays. The default choice for permanent gallery installations.
03
18,000 lumens for atrium-scale walls and biennial pavilions. Liquid-cooled standard housing with an optional silent-housing retrofit for white-cube contexts.
04
IP54-sealed outdoor housing, 9,500 lumens, factory-calibrated for dusk and ambient-light rejection. Engineered for courtyard commissions, facade projections, and permanent exterior installations.
Every figure below is measured at the factory and printed on the calibration certificate that ships inside the box. No typical values, no marketing rounding.
| Parameter | Atlas 04 | Meridian 08 | Helios 14 | Borealis 06 |
|---|---|---|---|---|
| Rec.2020 coverage | 97.4% | 98.1% | 96.8% | 97.9% |
| Factory ΔE (Rec.2020 ref.) | < 1 | < 1 | < 1 | < 1 |
| Native contrast | 4,000 : 1 | 5,000 : 1 | 5,500 : 1 | 4,500 : 1 |
| Brightness (ANSI lm) | 6,500 | 11,000 | 18,000 | 9,500 |
| Native resolution | 4K enhanced | Native 4K | Native 4K | Native 4K |
| APS-Edge blend nodes | 2 | 8 | 8 | 4 |
| Housing acoustic @ 1 m | 22 dB (silent) | 22 dB (silent) | 34 dB (standard) | 31 dB (outdoor) |
| Lens shift range | ±60% V / ±25% H | ±70% V / ±30% H | ±75% V / ±30% H | ±65% V / ±25% H |
| Light source life | 20,000 h | 20,000 h | 25,000 h | 20,000 h |
| Calibration tier | Atelier | Atelier | Atelier | Atelier |
| Color guarantee | 5 years | 5 years | 5 years | 5 years |
| In-box media pipeline | ArtLoop | ArtLoop | ArtLoop | ArtLoop |
| Weight | 18.4 kg | 26.1 kg | 42.8 kg | 34.2 kg |
| Bundle price (from) | €6,400 | €11,900 | €18,200 | €14,600 |
Calibration performed against a Rec.2020 reference at 6,500 K white point, measured with a Konica Minolta CA-410 at the factory bench. Certificate unique per serial number.
We chose Art Projectors Studio because the color the artist painted in post-production is the color that hits the wall. Anything else is a lie on a six-meter surface.
Pick a model, choose a lens, add a mount and gallery-grade cabling. Our bundle configurator ships the system pre-piped with ArtLoop — open the box, plug it in, project.
Configure Your Studio BundleMulti-room museum fit-out, biennial pavilion, permanent collection wing. Our 11 in-house projection engineers and 6 color-science specialists scope, install, and commission on-site.
Request a Fit-Out Quote
